Gantry cranes have a wide range of applications and are used in many industries. Buyers planning to buy a 10 ton gantry crane need to consider the following parameters in order buy a crane that is just right for their specific requirements.
The two most important things you need to pay attention to is the height and span. When it comes to height, you need to correctly measure the lowest object in the work area where the gantry crane is going to be installed. After all, the gantry crane is going to move stuff in and out of that area and it should fit underneath the lowest object. The lowest object could be the sprinklers, support beams, ceiling, pipes or a variety of other things.
The next important thing you need to consider is the overall height of the crane. It typically includes the distance from the top of the I-beam to the floor. There are adjustable height models also available and in that case, you need to measure the height appropriately. Another important factor that matters when it comes to height is the hook height. It refers to the highest point up to which the workload has to be lifted when it is secured. Do not forget to take into consideration any slack in the sling or the chain used for lifting the load.
Some of the other height considerations include headroom as well as chain fall. Headroom refers to the total height of the trolley and the hoist. Chain fall refers to the length of chain that is available for lifting. As mentioned in the above paragraphs, adjustable height models are also available and if you are considering such a model, you should consider investing in a height adjustment kit to make it easy to operate the crane.
When it comes to span, you need to consider a couple of things. Naturally, the most important part of the span is the measurement from one outside edge to the other outside edge. Since there are end stops to prevent the trolley from rolling off, you need to take this into account when deciding the width of the beam needed for the crane.
An important thing you need to look at is the capacity of the hoist. It should never exceed the crane capacity or capacity of the trolley. In an ideal scenario, the capacity of the hoist, trolley and the crane should be the same. An important safety consideration is to ensure that all the systems in your gantry crane shouldn’t exceed the maximum load that is expected to be lifted by the crane.
Reliable manufacturers typically test the crane at 125% of its rated capacity but it does not mean that you should regularly lift loads way higher than the rated capacity. In fact, the crane should never exceed the rated capacity to prevent any accidents.
Overall, these are some of the important things you need to consider in order to make the right choice when it comes to buying a 10 ton gantry crane. In addition, you should also take a close look at the reputation of the manufacturer. Check their customer reviews and ratings on various discussion forums and review websites dedicated to cranes and other heavy machinery to ensure you are buying from a reliable manufacturer. To learn more about Aicrane gantry crane, click here https://dafanggantrycrane.com/10-ton-gantry-crane/
